M3 Hexagon Flange Nut DIN 6923 A2 | Stainless Steel

Availability: duża ilość
Dispatched within: 24 godziny
Price: €0.01

Regular price:

0.01
quantity szt.

product unavailable

add to wish list
Pin It

Description

The DIN 6923 A2 M3 stainless steel hexagon flange nut combines a standard hex nut design with an integrated flange (washer-like base) that distributes load across a larger surface. This design helps prevent material deformation and loosening under vibration, eliminating the need for a separate washer and saving assembly time. Made from A2 (AISI 304) stainless steel, this flange nut offers excellent corrosion resistance, making it suitable for indoor and outdoor applications, machinery, structural assemblies, metal frames, and constructions exposed to moisture or harsh environments. Technical Specifications (M3 flange nut):

Technical Specifications (DIN 6923 A2 M3 Flange Nut)

  • Standard: DIN 6923 (hexagon nut with flange)
  • Material: A2 (AISI 304) stainless steel
  • Thread size (d): M3
  • dc: 7.8 mm
  • m: 3.8 mm
  • s: 6 mm
  • e: 6.33 mm
  • Feature: Integrated flange – acts as built-in washer for improved load distribution and stable fastening
